WRH-50B mini best laboratory use electric precious herbs dehydrator machine is suitable for drying a very large variety of food. Such as bird's nest drying, herb drying, fruit and vegetable drying, pet food drying, and other small batches of food drying. Contact us for free dehydrating testing!
Specifications for WRH-50B mini best home use electric precious herbs dehydrator Machine | ||
Main performance parameters | Material | Stainless steel |
Power supply | 220V / 50Hz / 60Hz | |
Power Input | 0.65KW | |
Running Current | 3.0A | |
Fast heating-up | 1.0KW | |
Maximum Power | 1.7Kw | |
Dehydration Amount | 1.6Kg/h ( @ 50℃,80%) | |
Working Temperature | 50~65℃ | |
Capacity | 10~50kg / batch | |
Noise Level | ≤50dB(A) | |
Wind Volume | 500m³/h | |
Machine Dimension(L*W*H) | 980*615*1050mm | |
Tray Size(L*W*H) | 500*500*30mm | |
Tray Number | 6 pcs (standard) | |
Net Weight | 70Kg | |
Gross Weight | 85Kg | |
MOQ | 1 Set | |
Warranty | 2 years | |
Lead Time | 10~30 working days | |
Payment terms | 1, We can offer different pricing of FOB, CIF and C&F. | |
Shipping | 1, We offer FOB Guangzhou and FOB Shenzhen to our customers. |
WRH-50B mini best home use electric precious herbs dehydrator Machine with adjustable temperature is our innovative product. It can dry any food in a gentle, fast and reliable way.
Its several advantages were unmatched by the traditional heat pump food dryer.
1, Gentle drying at middle and low temperature - Aroma, appearance and bioactivity are largely retained.
2, High efficiency through the use of a heat pump system for removing air humidity.
3, Drying in a closed sealed room, no foreign material pollution and no dependence from the climate.
4, All in one design, the operation directly after power switched on.
5, IKE graphical touch control system, automatic intelligent control and demands no human duty after setting.
6, Condensate available for further use.
1.Outline:
Drying oven using European technology design, with clean. Advanced technology, precise temperature control, stable performance, easy to maintained and operated.Be widely used in laboratory and mining enterprises, scientific research institutes, medical and other units for making drying, baking, melting wax heat treatment.
2.the structural characteristics
1) The shell is made of high quality cold-rolled or cold-rolled steel plate production, the surface coating process, clean and nice.
2)the liner is made of stainless steel or cold-rolled steel plate or embalmed, molding.
3)through the Intermediate steel door with glass viewing window, the situation of the heated items in the working chamber can be observed at anytime.
4)with the double-door design, it’s small occupation space, and easy to use. The high-temperature box door inlaid strips, keep sealing well and prevent heat loss.
5)it’s easy to observe and read the chamber temperature in the digital display.
6)Intelligent PID microprocessor thermostat with a timer, alarm function, and E-type sensor as the temperature measurement control system of the device, the measurement error is small and high precision temperature control.
7)the exhaust valve disposed in the side of chamber, the moisture discharged outside the box heater can be released at any time in the working process.
3.Specification
101 represents electric oven blast
S stands for intelligent digital temperature control instrumentation
B represents a stainless steel liner
4.principle of operation
After heated by electricity, and fan forced circulation , the air in the working chamber will be heated uniformly with the heat exchange in order to achieve the purpose of drying or baking.
5.Normal operating conditions
1) Power supply voltage: 220V ± 22V
2 )Ambient temperature: 5--40 ℃
3 )Relative Humidity: <90%
4) Pressure: 86--106KPa
6. The main technical parameters
Model | 101-00S/BS | 101-0S/BS | 101-1S/BS | 101-2S/BS | 101-3S/BS |
voltage | 220V 50HZ | ||||
range of room temperature | +5-300℃ | ||||
Temperature fluctuation | ±1℃ | ||||
Temperature uniformity | ±2.5% | ||||
power | 600w | 1000w | 1500w | 2000w | 3000w |
Studio Dimension (mm) | 250*250*250 | 350*350*350 | 350*450*450 | 450*550*550 | 500*600*700 |
Plate bearing | 15kg |
