drying oven stainless steel heat
-
v s
1. IKE industrial drying oven is developed and produced complying with concepts such as comfort, breathability, wrinkle resistance, and hygroscopicity, to meet the highest textile standards.
2. The product has a high cost performance for its strong functionality and high performance.
3. It has been tested by the harsh international first-class inspection standards.
4. The refinement of this product has driven a boom in many industries. It makes efficient mass production and increased productivity become true.
IKE food dehydrator WRH-300B has a compact structure, great energy-saving, wide application, high drying quality, easy operation, simple installation and removable. it is the best drying equipment for small firms, drying experiment and scientific research. optional "cloud" management function to achieve remote monitoring by computers and mobiles.
The users only connect the power to use, is the easiest operation heat pump dryer.
SPECIFICATIONS FOR WRH-300B | ||
Main performance parameters | Material | Stainless Steel 430/304 |
| Capacity | 200-350kg/batch | |
Power Supply | 220v/50Hz | |
Power Input | 3.0KW | |
Running Current | 15.0A | |
Fast heating-up | 3.0KW | |
Maximum Power | 6.0Kw | |
Dehydration Amount | 10.0Kg/h ( @ 50℃，80%） | |
Working Temperature | 50~65℃ | |
Noise Level | ≤65dB(A) | |
Wind Volume | 6500m3/h | |
Machine Dimension(L*W*H) | 1880*980*2100 mm | |
Net Weight | 250Kg | |
Gross Weight | 260Kg | |
Quality Control | IQC (Incoming quality check)；IPQC (In-process quality check)；OQC (Out-going quality check)；FQC (Final quality check) | |
Payment terms | 1, We can offer different pricing of FOB, CIF and C&F. | |
Shipping | 1, We offer FOB Guangzhou and FOB Shenzhen to our customers. | |
Drying essence is take moisture away, but takes away the moisture temperature is not the most critical factor. The key for drying is depending on relative humidity within certain space, IKE Company took advantage of the dry essence, originality developed a "Closed Cycle" dryer, changed the traditional heat pump dryer "bake" to "dehumidifier”. Its several advantages were unmatched by the traditional heat pump dryer.
more convenient when open or close the door
Applicable locations and situations for WRH-300B: dried fruit production, sausage production, rare chinese herbal medicine, initial processing for produce, etc.
Fruits
apple drying, banana drying, lemon drying, longan drying, kiwi drying, grape drying, etc.Vegetables
tomato drying, sweet potato drying, potato drying, chilli drying, etc.Flowering teas
yellow chrysanthemum drying, rose flower drying, pomelo flower drying, etc.
Meat
pork drying, beef drying, dog treat drying, chicken drying, sausage drying, etc.Seafood
fish drying, squid drying, shrimp drying, sea cucumber drying, etc.Herbal medicine
orange peel drying, moringa leaves drying, maca drying, lonicera japoniac drying, etc.
Strong wind dehumidification drying in 25℃~65℃, articles does no damage, no moldy and maintain nutrition.
Drying in a closed sealed room, no foreign material pollution. Efficiency is irrelevant to external environment, that can maintain high energy efficiency at all seasons. No hot air and water vapor loss maximize energy recovery.
All in one design, operation directly after power switched on. Graphical touch control system, automatic intelligent control and demands no human duty after setting.
Company Features
1. Guangdong IKE Industrial Co.,Ltd. becomes competitive for the well-made industrial drying oven . We have devoted to R&D and manufacture for years.
2. The quality for our drying oven is so great that you can definitely rely on.
3. Guangdong IKE Industrial Co.,Ltd.'s food dehydrator supplies is a symbol of strong production capabilities. Get quote! Our unique service has a place in the large dehydrator industry. Get quote!
Interduction and properties:
Cabinet Dryer is applicable for drying all kinds polymer materials and can simultaneously dry different materials,and is very suitable for diversified raw materials of low amount or testing mould,and is aslo applicable for preheating or drying related products such as electtonics,motor,electroplating,coat baking,printing and tea.
1.Adopt computerized temperature control with even drying effect;
2.The high temperature seal door keeps accordant temperature and drops heat loss;
3.Stainless steel baking plate and internal wall can prevent pollution during the drying the drying process;
4.Optimized design,convenient for repair and maintenance;
5.Air inlet and outlet are adjustable,convenient for adjusting the air quantity;
6.24h timing device,convenient for operation and over temperature protector,avoid over temperature drying;
7.Motor overload protection;
8.Alarm indicator,immediately react when there's fault;
9.Baking plate or entire machine are customized according to client's demands;
Technical parameters:
Model | Electric Heating Power(kw) | Fan Motor(kw) | Highest Temperature(°C) | Number of Platerack(plate) | Material Feeding Capacity(kg) | External Dimension(mm) | Internal Dimension(mm) | Net weight(kg) |
MCD-5 | 4 | 0.37 | 250 | 5 | 50 | 1200x600x610 | 660x600x550 | 150 |
Model | Electric Heating Power(kw) | Fan Motor(kw) | Highest Temperature(°C) | Number of Platerack(plate) | Material Feeding Capacity(kg) | External Dimension(mm) | Internal Dimension(mm) | Net weight(kg) |
MCD-9 | 4.5 | 0.37 | 250 | 9 | 90 | 1440x800x610 | 900x600x550 | 180 |
Model | Electric Heating Power(kw) | Fan Motor(kw) | Highest Temperature(°C) | Number of Platerack(plate) | Material Feeding Capacity(kg) | External Dimension(mm) | Internal Dimension(mm) | Net weight(kg) |
MCD-20 | 9 | 1.5 | 250 | 20 | 200 | 1700x1210x860 | 1000x990x800 | 415 |
IKE: Smart Drying, Industry Defining.
Your Trusted Commercial and Industrial Food Dehydrator Manufacturer, Specializing in High-Quality Drying Solutions Since 1994.
